Brand: Dell
Raw node capacity:7.7 TB - 61 TB
Nodes per cluster:3 up to 252
Raw cluster capacity:23 TB to 15 PB
Memory:128 GB
Storage type:NVMe SSD (TLC, QLC)
SSD drives per node:4
Processor: 2 Intel Xeon CPUs, 2GHz/10C
Functional: All-flash, all-NVMe NAS, Scale-out storage
Memory: 128 GB DRAM DDR5 ECC
Base enclosure: 1U Form Factor, 4x2.5” NVMe SSD drives
Expansion Capacity: Scale-out architecture, Distributed fully symmetric clustered architecture that combines modular storage with OneFS operating system in a single volume, single namespace, and single filesystem.
Expansion enclosures: Minimum cluster size: 3 nodes, Maximum cluster size: 252 nodes
Front End Networking (per node): Dual port 25G NIC supporting 10G or 25G connections (SFP+/SFP28), Dual port 100G NIC supporting 40G or 100G connections
Infrastructure Networking (per node): Dual port 25G NIC supporting 10G or 25G connections (SFP+/SFP28), Dual port 100G NIC supporting 40G or 100G connections (QSFP+/QSFP28)
Software: OneFS 9.2.1 or later. Upgrades are non-disruptive, PowerScale OneFS distributed file system creates a cluster with a single file system and
Base unit: 1U Form Factor
Height: 42.8 mm / 1.68 in.
Width: 482 mm / 18.97 in.
Depth: 822.88 mm / 32.39 in. (with bezel)
Weight: 20.3 kg / 44.8 lb
Power: 800 W, Dual redundant power supplies
Max Power consumption: (200-240V per node), 25°C – 286 Watts, 35°C – 309 Watts
Typical Thermal rating: 25°C – 975 BTU/hr, 35°C – 1054 BTU/hr
